Useful generation — already started
Useful generation = Year-1 generation × self-consumption
Cells: Your Model!B4:D4
System A formula in B4:
='Case Data'!B15*'Case Data'!B16
Copy B4 across to D4. Relative references should change automatically.
02 · Build
Cape Manufacturing solar investment case — Build your model in Excel
Case study · Cape Manufacturing · The Year-1 comparison
The inputs are understood and your first useful-generation calculation is in place. Management now needs the same financial measures for all three proposals.
Stage outcome and evidence
Outcome for this stage: Construct an auditable spreadsheet model that converts operational solar data into comparable Year-1 financial measures.
Evidence: completed Your Model!B4:D7 (optional ranks in row 8), one comparison chart and a one-sentence visual-design rationale.
Microsoft Excel · Build
Excel formatting Select B5:D6 → Home → Number and choose Currency/Accounting. Select B7:D7 and show two decimal places.
Google Sheets compatibility — formatting Select B5:D6 → Format → Number → Currency (or use the currency toolbar button). Select B7:D7 → Format → Number → Number and set two decimal places.
Course guidance · build the comparison
Turn three supplier proposals into one auditable model
Management needs a common basis for comparison. Build the logic in the Your Model sheet: useful generation → gross saving → net saving → simple payback.
1
2
Gross Year-1 saving
Gross saving = useful generation × tariff
Select Your Model!B5 and enter:
=B4*'Case Data'!$B$4
Copy across to D5. The first reference changes B4 → C4 → D4; the tariff stays locked at Case Data!$B$4.
Check your answer
B5 = R231,840; C5 = R287,980; D5 = R321,048.
Check your model · a copied reference
A colleague’s formula in Your Model!C5 is =C4*'Case Data'!C4. It should calculate System B’s gross saving. Inspect Case Data!C4: why will this formula fail, and how should you correct it before copying across?
Check your answer
C4 on Case Data contains the unit label, not the tariff. The tariff reference has moved during copying. Use =C4*'Case Data'!$B$4: useful generation remains relative, while the tariff stays fixed. The result should be R287,980. Correct the original formula in B5 too, then inspect D5 after copying.
3
Net Year-1 saving
Net saving = gross saving − maintenance
In Your Model!B6 enter:
=B5-'Case Data'!B17
Copy across to D6. Format B6:D6 as rand currency.
Check your answer
B6 = R222,840; C6 = R276,980; D6 = R307,048.
4
Simple payback
Simple payback = installed cost ÷ Net Year-1 saving
In Your Model!B7 enter:
='Case Data'!B13/B6
Copy across to D7. Format B7:D7 to two decimal places.
Check your answer
Your answers should be approximately A = 2.92, B = 2.96, C = 3.22 years. If not, check percentage formats, cell references, subtraction of maintenance, and numerator/denominator.
Optional Excel skill · rank the paybacks
Use a function rather than ranking by eye
In Your Model!B8 enter:
=RANK.EQ(B7,$B$7:$D$7,1)
Copy across to D8. The final argument 1 means the smallest payback receives rank 1.
Check your answer
System A = 1, System B = 2, System C = 3.
Visual communication task
Create one chart an executive can read in five seconds
- Decide which single comparison your chart should communicate.
- For a simple-payback chart, use proposal names
B3:D3and payback valuesB7:D7.
Excel Select B3:D3, then add the non-adjacent B7:D7 range using Ctrl (Windows) or ⌘ (Mac). Choose Insert → Column or Bar Chart → Clustered Column.
Google Sheets compatibility The simplest beginner route is to create a small temporary two-row chart source in unused cells (for example H3:J4): copy the three proposal names into row 3 and link row 4 to B7:D7. Select H3:J4 → Insert → Chart → choose Column chart in the Chart editor. This avoids awkward non-adjacent selection.
- Give the chart a decision-focused title such as Simple payback by proposal.
- Remove anything that does not help a manager compare the three systems.
Write one sentence: “I chose to show ___ because ___.”
Completed: completed Your Model!B4:D7 (optional ranks in row 8) + one chart + one-sentence design rationale.
Next: management challenges an assumption. Test whether your conclusion survives.
Glossary & further reading · optional
- Useful generation
- Solar electricity the factory uses when it is generated. In this model it equals total Year-1 generation multiplied by self-consumption, measured in kWh.
- Gross saving
- The cost of grid electricity avoided before deducting maintenance: useful generation multiplied by the tariff. This is a saving, not revenue from selling electricity.
- Net Year-1 saving
- Gross Year-1 saving after subtracting the model’s Year-1 maintenance cost. It is a modelled cash saving, not accounting profit.
- Maintenance cost
- The recurring cost of keeping the solar system working. The course deducts the supplied annual maintenance amount from gross savings.
- Simple payback period
- An estimate of how long savings take to recover the initial cost. Installed cost divided by net Year-1 saving assumes that saving repeats, and ignores discounting and savings after payback.
- Ranking
- Ordering the proposals by a chosen measure. Here, the shortest payback gets rank 1; that ranking does not establish which proposal has the greatest long-term value.
- Auditable model
- A model whose results can be traced through formulas to their source inputs and checked. Referencing Case Data helps preserve that traceability.
